| Main specification | |
| Type | 40ft container skeletal semi trailer |
| Function | 40ft container, 2x20 ft container or 1x20ft container transportation |
| Overall dimensios | 7200x2500x1550 mm |
| Loading weight | 40,000 kg |
| Container twist lock | 4 pcs |
| Main beam | Q345B steel |
| The height of the beam is 500mm, | |
| upper plate is 14mm, | |
| down plate is 16mm, | |
| middle plate is 8mm | |
| Side beam | 16 U shaped steel or I shaped steel |
| Chassis | |
| Axle brand | 13 ton FUWA Brand axle |
| Axle number | 3 axle |
| Landing gear | Standard 28 ton, JOST etc optional |
| Suspension system | Mechanical suspension |
| Steel spring | 10/10 |
| Tire | 12R22.5 |
| Tire quantity | 6 |
The factory details
Company Information
Certifications
Contact
Jay sales manager
